Bowl Liner (Concave)

A bowl liner, also known as a concave, a stationary wear part installed inside the upper frame of a cone crusher to form the crushing chamber.

Mining & Crushers

Cone / Mantle Liner

The cone crusher mantle (or cone liner) is the moving protective wear part mounted on the crusher's main shaft assembly

Mining & Crushers

Cone Crusher Socket Liner

A cone crusher socket liner is a replaceable bronze wear part that sits inside the socket assembly to support the main shaft and provide a smooth, low-friction bearing surface

Cement

Mill Liners

A ball mill liner is a protective inner shell attached inside a grinding mill to shield the equipment from heavy impact and wear caused by grinding media (like steel balls) and ore

Mining & Crushers

Blow Bar

Impact crusher blow bars are thick metal bars attached to a rotor that spin at high speeds to break down materials like rock, concrete, and asphalt

Mining & Crushers

Impact Plates

Mining & Crushers

Fixed Jaw Plate

Fastened securely to the stationary front frame of the crusher. It remains completely still and absorbs the direct impact of incoming, uncrushed rock.

Mining & Crushers

Jaw Crusher Cheek Plate

White iron option: extremely hard (wear-resistant) but brittle – suitable only where impact energy is low. Mn steel: tough and work-hardening – better for high impact. Selection depends on feed material hardness and fragmentation.

Mining & Crushers

Jaw Crusher Wedge

Mining & Crushers

Moving Jaw Plate

Attached to the moving swing jaw (pitman) assembly. It moves in an elliptical or linear rocking motion to actively squeeze and crush the material against the fixed plate.

Mining & Crushers

Toggle Plate

Toggle transmits crushing force – high compressive load. Cast steel (not Mn) – high compressive strength required not wear resistance.

Mining & Crushers

Wear Plate

A rectangular plate with dimensions 350 x 280 x 35 mm, featuring a central cylindrical protrusion with a through-hole. Likely used as a wear-resistant liner or impact plate in heavy-duty crushing or breaking applications.

Mining & Crushers

Grizzly Bar for Vibrating Feeder

Grizzly bars are heavy-duty, wear-resistant screening bars mounted at the discharge end of a vibrating grizzly feeder. They act as a coarse primary scalper, allowing smaller rocks, soil, and fines to fall through the gaps while sliding oversized boulders directly into the primary crusher
